All advantages at a glance:

Wide temperature and humidity range from 5°C to 50°C and from 5%RH to 95%RH

Easy operation, fast regulation, good stability and homogeneity

Fast stabilisation time (e.g. 3 min from 35%RH to 80%RH at 25°C) ü Highest measuring stability due to optimal insulation of the chamber and high-end sealing adapter plate

Large measuring chamber (Ø 160 mm, depth 320 mm)

No condensation inside the measuring chamber through a regulation along the dew point

Guaranteed mobility- the compact size and the minimal weight ensure an extremely flexible use of the Huminator II.

New touch display enables a fast and intuitive operation

Graphical and tabular view as well as storage and evaluation of measured values

Integrated, easily accessible and replaceable reference sensor, that eliminates the need for an external reference system

Possibility to program measuring points and procedures individually

Technical Data Specifications

Measuring and control range:

5 to 50 °C

5 ... 95 %RH

Stability :

± 0.02 °C (at 25 °C; 50 %RH) ± 0,3 %RH (10 ... 80 %RH bei 10 ... 40 °C)

± 0,5 %RH (rem. measuring range)

Probe accuracy at 25 °C:

± 0.15 °C (0.27 °F) with PT1000 Class AA

± (1,0 %RH + 0,007 x meas. value) für 0 ... 90 %RH

Homogeneity:

± 0.2°C

± 0,5 %RH

Stabilization time: 3 min (from 35 to 80 %RH at 25 °C)

Ambient conditions: 20 ± 5 °C

Typical total measuring uncertainty of the calibration (k=2):

± 0.2 °C (10 to 85 %RH at 25 °C) ± 0.5 °C (rem. measuring range)

± 1.5 %RH (10 to 85 %RH at 25 °C) ± 2.0 %RH (rem. measuring range)

General data

Display: Touchscreen

Number of probe slots: 5

Interfaces: USB, LAN

Power consumption (typical): 30 W to 250 W, max: 500 W

AC input voltage/ -frequency:110 V to 230 V ±10 % 50/60 Hz

Tank volume: Tank with a capacity of 200 ml

Water level indicator Completely automatically with graphic display

Display of measuring data: In graphic and tabular form

Control: Manually or automatically programmable

Stabilization signal: visually and acoustically

Dimensions (DxWxH)

451 mm x 448 mm x 266 mm

482 mm x 448 mm x 290 mm (incl. attachements)

Size of the measuring chamber: Diameter: 160 mm Depth: 320 mm

Volume oft he measuring chamber: appr. 4.2 liters (inlet: 154 mm, Depth to cooling element: 230 mm)

Weight: 19 kg
